SQL Server GROUP BY, ROLLUP, CUBE, GROUPING SETS and PIVOT (2026)

1. GROUP BY Fundamentals

GROUP BY collapses multiple rows that share the same values in the listed columns into a single summary row. Every column that appears in the SELECT list outside of an aggregate function (SUM, COUNT, AVG, MIN, MAX) must be present in the GROUP BY clause — SQL Server enforces this at parse time.

Common aggregate functions recap:

• COUNT(*) — number of rows in the group
• COUNT(col) — non-NULL values only
• COUNT(DISTINCT col) — distinct non-NULL values
• SUM(col) / AVG(col) — total / mean of numeric column
• MIN(col) / MAX(col) — range extremes
• STRING_AGG(col, sep) (SQL Server 2017+) — concatenate strings within group

-- Basic GROUP BY: total sales per region
SELECT
    Region,
    COUNT(OrderID)   AS OrderCount,
    SUM(Amount)      AS TotalSales,
    AVG(Amount)      AS AvgOrderValue
FROM dbo.Orders
GROUP BY Region
ORDER BY TotalSales DESC;

2. GROUP BY with HAVING

WHERE filters rows before grouping; HAVING filters groups after aggregation. Using WHERE to pre-filter rows that will never contribute to a result is always more efficient than filtering with HAVING alone.

-- Find regions with more than 500 orders AND total sales > 1,000,000
SELECT
    Region,
    COUNT(OrderID)   AS OrderCount,
    SUM(Amount)      AS TotalSales
FROM dbo.Orders
WHERE OrderDate >= '2025-01-01'   -- filter rows FIRST (uses index)
GROUP BY Region
HAVING COUNT(OrderID) > 500
   AND SUM(Amount) > 1000000
ORDER BY TotalSales DESC;

SQL Server evaluates the logical query plan in this order: FROM → WHERE → GROUP BY → HAVING → SELECT → ORDER BY. Aggregate expressions like SUM(Amount) are not yet computed during the WHERE phase, which is why you cannot write WHERE SUM(Amount) > 1000000.

3. GROUP BY ALL (Deprecated) and DISTINCT Grouping Patterns

GROUP BY ALL was a SQL Server extension that included groups filtered out by WHERE (returning NULLs for their aggregates). It was deprecated in SQL Server 2008 and removed in SQL Server 2022. Do not use it in new code.

A common modern pattern is using DISTINCT to de-duplicate without aggregating, or combining GROUP BY with a window function for ranked or filtered aggregation:

-- Modern replacement: use a subquery or CTE instead of GROUP BY ALL
SELECT r.Region, ISNULL(s.TotalSales, 0) AS TotalSales
FROM (SELECT DISTINCT Region FROM dbo.RegionMaster) r
LEFT JOIN (
    SELECT Region, SUM(Amount) AS TotalSales
    FROM dbo.Orders
    WHERE OrderDate >= '2025-01-01'
    GROUP BY Region
) s ON r.Region = s.Region;

4. ROLLUP: Subtotals and Grand Totals

GROUP BY ROLLUP(col1, col2, col3) generates subtotal rows at each level of the column hierarchy, plus a grand total row. For n columns it produces n+1 grouping sets. This is far more efficient than writing multiple GROUP BY queries and combining them with UNION ALL.

-- Sales by Year → Region → Month, with subtotals at every level
SELECT
    ISNULL(CAST(YEAR(OrderDate) AS VARCHAR), 'Grand Total') AS SalesYear,
    ISNULL(Region,  '-- All Regions')                       AS Region,
    ISNULL(DATENAME(MONTH, OrderDate), '-- All Months')     AS SalesMonth,
    SUM(Amount)                                             AS TotalSales,
    COUNT(OrderID)                                          AS OrderCount
FROM dbo.Orders
GROUP BY ROLLUP(
    YEAR(OrderDate),
    Region,
    DATENAME(MONTH, OrderDate)
)
ORDER BY
    YEAR(OrderDate),
    Region,
    MONTH(MIN(OrderDate));

The query above produces:

• Detail rows: Year + Region + Month
• Month subtotals rolled into Region: Year + Region (Month = NULL)
• Region subtotals rolled into Year: Year (Region = NULL, Month = NULL)
• Grand total: all NULLs

5. CUBE: All Possible Subtotal Combinations

GROUP BY CUBE(col1, col2, col3) generates subtotals for every possible combination of the listed columns — 2ⁿ grouping sets for n columns. It is ideal for cross-tabulation / OLAP-style reporting where you need all marginal totals simultaneously.

-- Cross-tab: sales by Region × ProductCategory × SalesRep
-- Generates all 8 combinations (2^3) including grand total
SELECT
    ISNULL(Region,          'All Regions')    AS Region,
    ISNULL(ProductCategory, 'All Categories') AS ProductCategory,
    ISNULL(SalesRep,        'All Reps')       AS SalesRep,
    SUM(Amount)                               AS TotalSales
FROM dbo.Orders
GROUP BY CUBE(Region, ProductCategory, SalesRep)
ORDER BY
    GROUPING(Region),
    GROUPING(ProductCategory),
    GROUPING(SalesRep),
    Region, ProductCategory, SalesRep;

Ordering by GROUPING() puts detail rows first and grand totals last — useful for report rendering. CUBE with many columns can produce very large result sets; prefer GROUPING SETS when you need only a subset of combinations.

6. GROUPING SETS: Custom Grouping Combinations

GROUPING SETS lets you specify exactly which grouping combinations you want, without the combinatorial explosion of CUBE. It replaces multiple GROUP BY queries stitched together with UNION ALL — and it processes the data in a single scan, making it significantly faster.

-- Equivalent to three separate GROUP BY + UNION ALL, but far more efficient
SELECT
    Region,
    ProductCategory,
    SalesRep,
    SUM(Amount) AS TotalSales
FROM dbo.Orders
GROUP BY GROUPING SETS (
    (Region, ProductCategory),   -- subtotal per region+category
    (Region),                    -- subtotal per region only
    (SalesRep),                  -- subtotal per sales rep
    ()                           -- grand total (empty set)
)
ORDER BY
    GROUPING(Region),
    GROUPING(ProductCategory),
    Region, ProductCategory;

GROUPING SETS also composes with ROLLUP and CUBE inside a single clause:

-- Mixed: ROLLUP on (Year, Region) PLUS a separate SalesRep subtotal
GROUP BY GROUPING SETS (
    ROLLUP(YEAR(OrderDate), Region),
    (SalesRep)
)

7. GROUPING() and GROUPING_ID() Functions

When ROLLUP or CUBE introduce NULL-filled subtotal rows, you need a way to distinguish them from genuine NULL data values. The GROUPING(col) function returns 1 when the column is aggregated (i.e., it is a subtotal row for that column) and 0 when it is a real group-by value. GROUPING_ID(col1, col2, ...) packs all the GROUPING bits into a single integer bitmask.

-- Use GROUPING() to label rows correctly even when data has real NULLs
SELECT
    CASE GROUPING(Region)
        WHEN 1 THEN 'Grand Total'
        ELSE ISNULL(Region, '(Unknown Region)')
    END                     AS Region,
    CASE GROUPING(ProductCategory)
        WHEN 1 THEN '-- All Categories'
        ELSE ISNULL(ProductCategory, '(Unassigned)')
    END                     AS ProductCategory,
    SUM(Amount)             AS TotalSales,
    GROUPING(Region)        AS IsRegionSubtotal,
    GROUPING(ProductCategory) AS IsCatSubtotal,
    GROUPING_ID(Region, ProductCategory) AS GroupingLevel
FROM dbo.Orders
GROUP BY ROLLUP(Region, ProductCategory)
ORDER BY GroupingLevel, Region, ProductCategory;

GROUPING_ID values for a two-column ROLLUP: 0 = detail, 1 = Region subtotal (Category rolled up), 3 = grand total.

8. Static PIVOT: Transforming Rows to Columns

PIVOT rotates distinct values from one column into multiple output columns, applying an aggregate to each cell. When the set of pivot values is known at design time, a static PIVOT is simple and performs well.

-- Pivot quarterly sales: rows = Region, columns = Q1 Q2 Q3 Q4
SELECT
    Region,
    ISNULL([Q1], 0) AS Q1_Sales,
    ISNULL([Q2], 0) AS Q2_Sales,
    ISNULL([Q3], 0) AS Q3_Sales,
    ISNULL([Q4], 0) AS Q4_Sales,
    ISNULL([Q1], 0) + ISNULL([Q2], 0) +
    ISNULL([Q3], 0) + ISNULL([Q4], 0) AS YearTotal
FROM (
    -- Source query: produce region, quarter label, and amount
    SELECT
        Region,
        'Q' + CAST(DATEPART(QUARTER, OrderDate) AS CHAR(1)) AS Quarter,
        Amount
    FROM dbo.Orders
    WHERE YEAR(OrderDate) = 2025
) AS SourceData
PIVOT (
    SUM(Amount)
    FOR Quarter IN ([Q1], [Q2], [Q3], [Q4])
) AS PivotTable
ORDER BY Region;

9. Dynamic PIVOT: Unknown Column Values with Dynamic SQL

When the pivot column values are not known at query-write time (e.g., product names change, new regions are added), you must build the column list at runtime using dynamic SQL.

-- Dynamic PIVOT stored procedure: pivot sales by any product
CREATE OR ALTER PROCEDURE dbo.usp_SalesByProductPivot
    @Year INT = 2025
AS
BEGIN
    SET NOCOUNT ON;

    -- Step 1: collect distinct pivot column names (sanitised)
    DECLARE @cols NVARCHAR(MAX) = '';
    DECLARE @colsNull NVARCHAR(MAX) = '';

    SELECT
        @cols     = @cols     + ', ' + QUOTENAME(ProductName),
        @colsNull = @colsNull + ', ISNULL(' + QUOTENAME(ProductName) + ', 0) AS ' + QUOTENAME(ProductName)
    FROM (
        SELECT DISTINCT TOP 200 ProductName
        FROM dbo.Orders
        WHERE YEAR(OrderDate) = @Year
        ORDER BY ProductName
    ) t;

    -- Remove leading comma
    SET @cols     = STUFF(@cols,     1, 2, '');
    SET @colsNull = STUFF(@colsNull, 1, 2, '');

    -- Step 2: build the full dynamic SQL string
    DECLARE @sql NVARCHAR(MAX) = N'
    SELECT Region, ' + @colsNull + N'
    FROM (
        SELECT Region, ProductName, Amount
        FROM dbo.Orders
        WHERE YEAR(OrderDate) = ' + CAST(@Year AS NVARCHAR) + N'
    ) AS src
    PIVOT (
        SUM(Amount)
        FOR ProductName IN (' + @cols + N')
    ) AS pvt
    ORDER BY Region;';

    -- Step 3: execute safely
    EXEC sp_executesql @sql;
END;
GO

-- Usage
EXEC dbo.usp_SalesByProductPivot @Year = 2025;

10. UNPIVOT: Transforming Columns Back to Rows

UNPIVOT is the inverse of PIVOT — it normalises a wide (denormalised) table with many columns back into a tall (normalised) table with fewer columns. This is common when consuming reporting data that arrived pre-pivoted.

-- Source: wide table with one column per quarter
-- Goal: normalise to (Region, Quarter, Sales)
SELECT Region, Quarter, Sales
FROM (
    SELECT Region, Q1_Sales, Q2_Sales, Q3_Sales, Q4_Sales
    FROM dbo.RegionalQuarterlySales
    WHERE SalesYear = 2025
) AS WideSrc
UNPIVOT (
    Sales FOR Quarter IN (Q1_Sales, Q2_Sales, Q3_Sales, Q4_Sales)
) AS UnpivotResult
ORDER BY Region, Quarter;

UNPIVOT automatically excludes NULL cells — it only returns rows where the value column is non-NULL. If you need NULLs in the output, use a CROSS APPLY VALUES pattern instead:

-- CROSS APPLY VALUES: normalise including NULLs
SELECT r.Region, v.Quarter, v.Sales
FROM dbo.RegionalQuarterlySales r
CROSS APPLY (VALUES
    ('Q1', r.Q1_Sales),
    ('Q2', r.Q2_Sales),
    ('Q3', r.Q3_Sales),
    ('Q4', r.Q4_Sales)
) AS v(Quarter, Sales)
WHERE r.SalesYear = 2025
ORDER BY r.Region, v.Quarter;

11. MERGE Statement: INSERT / UPDATE / DELETE in One

MERGE synchronises a target table with a source dataset in a single atomic statement. It is the standard upsert pattern in SQL Server — replacing the error-prone "check then insert/update" antipattern.

-- Upsert: sync staging data into the production sales summary
MERGE dbo.SalesSummary AS target
USING (
    SELECT Region, ProductCategory, SUM(Amount) AS TotalSales, COUNT(*) AS OrderCount
    FROM dbo.OrdersStaging
    GROUP BY Region, ProductCategory
) AS source
ON  target.Region          = source.Region
AND target.ProductCategory = source.ProductCategory

-- Row exists in both: update the totals
WHEN MATCHED THEN
    UPDATE SET
        target.TotalSales  = source.TotalSales,
        target.OrderCount  = source.OrderCount,
        target.UpdatedAt   = SYSUTCDATETIME()

-- Row exists in source only: insert new summary row
WHEN NOT MATCHED BY TARGET THEN
    INSERT (Region, ProductCategory, TotalSales, OrderCount, CreatedAt)
    VALUES (source.Region, source.ProductCategory,
            source.TotalSales, source.OrderCount, SYSUTCDATETIME())

-- Row exists in target only (stale/removed): delete it
WHEN NOT MATCHED BY SOURCE THEN
    DELETE

-- Optional: capture what happened
OUTPUT
    $action           AS MergeAction,
    inserted.Region,
    inserted.ProductCategory,
    inserted.TotalSales;

12. Performance Considerations

ROLLUP vs Multiple GROUP BY + UNION ALL

SQL Server's query optimizer recognises ROLLUP/CUBE/GROUPING SETS and can handle them with a single table scan + sort/hash aggregation pass. Multiple GROUP BY … UNION ALL queries each require a separate scan. On large fact tables with hundreds of millions of rows, ROLLUP can be 3–10× faster.

Index Design for Aggregation Queries

• Covering index: include all columns referenced in GROUP BY, aggregate functions, and WHERE clauses in one non-clustered index. This enables an index scan instead of a full table scan.
• Columnstore indexes (SQL Server 2012+): batch-mode execution on columnstore dramatically accelerates aggregation — GROUP BY queries on columnstore can be 10–100× faster than row-store with equivalent row counts.
• Partition elimination: partition the fact table on the most selective filter column (e.g., OrderDate year/month). ROLLUP queries filtered to a date range will scan only the relevant partitions.

-- Covering index for the quarterly pivot query
CREATE NONCLUSTERED INDEX IX_Orders_Region_Date_Amount
ON dbo.Orders (Region, OrderDate)
INCLUDE (Amount, OrderID, ProductName);

-- Or go columnstore for OLAP workloads
CREATE NONCLUSTERED COLUMNSTORE INDEX IX_Orders_CS
ON dbo.Orders (Region, ProductName, OrderDate, Amount, OrderID);

13. Practical Use Case: Sales Dashboard Query

Combining GROUPING SETS with a subsequent PIVOT gives you a compact, single-pass sales dashboard that covers every dimension your reporting layer needs.

-- Step 1: compute all needed groupings in one pass with GROUPING SETS
WITH SalesAgg AS (
    SELECT
        ISNULL(Region, 'All')                               AS Region,
        ISNULL(ProductCategory, 'All')                      AS ProductCategory,
        ISNULL(CAST(YEAR(OrderDate) AS VARCHAR(4)), 'All')  AS SalesYear,
        SUM(Amount)                                         AS TotalSales,
        COUNT(OrderID)                                      AS OrderCount,
        GROUPING_ID(Region, ProductCategory,
                    YEAR(OrderDate))                        AS GrpLevel
    FROM dbo.Orders
    WHERE OrderDate >= '2024-01-01'
    GROUP BY GROUPING SETS (
        (Region, ProductCategory, YEAR(OrderDate)),  -- full detail
        (Region, ProductCategory),                   -- subtotal: omit year
        (Region),                                    -- subtotal: region only
        ()                                           -- grand total
    )
),
-- Step 2: pivot the years into columns
Pivoted AS (
    SELECT *
    FROM SalesAgg
    PIVOT (
        SUM(TotalSales)
        FOR SalesYear IN ([2024], [2025], [2026], [All])
    ) AS pvt
)
-- Step 3: final output with year-over-year growth
SELECT
    Region,
    ProductCategory,
    GrpLevel,
    ISNULL([2024], 0) AS Sales_2024,
    ISNULL([2025], 0) AS Sales_2025,
    ISNULL([2026], 0) AS Sales_2026,
    ISNULL([All],  0) AS GrandTotal,
    CASE WHEN ISNULL([2024], 0) = 0 THEN NULL
         ELSE ROUND(100.0 * (ISNULL([2025], 0) - ISNULL([2024], 0))
                    / ISNULL([2024], 0), 2)
    END                AS YoY_Growth_Pct
FROM Pivoted
ORDER BY GrpLevel, Region, ProductCategory;

This pattern produces a ready-to-display matrix that a reporting tool (SSRS, Power BI, or a web front-end) can render directly as a cross-tab — no client-side pivot logic required.

Summary

Read Next
