SQL Server Statistics: How They Work, Auto-Update and Maintenance (2026)

What Are Statistics Objects

A statistics object is a binary blob stored in the system catalog that describes the distribution of values in one or more columns. SQL Server creates statistics objects automatically when:

• You create an index (statistics are created on the index key columns)
• The query optimizer needs selectivity information for a column used in a WHERE clause or JOIN condition and AUTO_CREATE_STATISTICS is ON

You can also create them manually with CREATE STATISTICS. Each statistics object contains:

• A header — row count, page count, sample rate, last update time
• A density vector — selectivity for column prefixes
• A histogram — up to 200 steps showing value distribution for the leading column

To list all statistics objects on a table:

SELECT
    s.name           AS stats_name,
    s.auto_created,
    s.user_created,
    s.has_filter,
    s.filter_definition,
    sp.last_updated,
    sp.rows,
    sp.rows_sampled,
    sp.modification_counter
FROM sys.stats s
CROSS APPLY sys.dm_db_stats_properties(s.object_id, s.stats_id) sp
WHERE s.object_id = OBJECT_ID('dbo.Orders')
ORDER BY sp.last_updated DESC;

The Histogram: RANGE_HI_KEY and EQ_ROWS

The histogram captures value distribution for the leading column of a statistics object, divided into up to 200 steps. Each step covers a value range and contains five values:

DBCC SHOW_STATISTICS ('dbo.Orders', 'IX_Orders_OrderDate') WITH HISTOGRAM;

Sample output:

RANGE_HI_KEY            EQ_ROWS   RANGE_ROWS   DISTINCT_RANGE_ROWS   AVG_RANGE_ROWS
----------------------  --------  -----------  --------------------  ---------------
2024-01-31 00:00:00.000    1250      0.0              0                   1.0
2024-02-29 00:00:00.000    1190   38400.0            30                1280.0
2024-03-31 00:00:00.000    1310   41200.0            28                1471.4
...

• RANGE_HI_KEY — the upper boundary value of this step
• EQ_ROWS — estimated rows equal to RANGE_HI_KEY
• RANGE_ROWS — estimated rows between the previous step's RANGE_HI_KEY and this one (exclusive)
• DISTINCT_RANGE_ROWS — number of distinct values in RANGE_ROWS
• AVG_RANGE_ROWS — RANGE_ROWS / DISTINCT_RANGE_ROWS — what the optimizer uses for equality predicates on non-boundary values

When you write WHERE OrderDate = '2024-03-15', the optimizer falls between two RANGE_HI_KEY boundaries and uses AVG_RANGE_ROWS as its row estimate. A value at a boundary uses EQ_ROWS exactly.

The Density Vector: Multi-Column Selectivity

The density vector contains one row per column prefix. For a statistics object on (CustomerID, OrderDate, Status), you get three density rows:

DBCC SHOW_STATISTICS ('dbo.Orders', 'IX_Orders_Customer_Date') WITH DENSITY_VECTOR;

All density   Average Length  Columns
------------- ---------------  ---------------------------------
0.0001        4.0              CustomerID
0.000025      12.0             CustomerID, OrderDate
0.0000083     13.0             CustomerID, OrderDate, Status

All density = 1 / (number of distinct values). Lower density means higher selectivity. Density for CustomerID alone of 0.0001 means 10,000 distinct values in the table (1/0.0001). The optimizer multiplies density by the table's row count to estimate rows for equality predicates beyond the first column.

Reading Statistics with DBCC SHOW_STATISTICS

The full syntax returns all three parts of a statistics object:

-- All three parts
DBCC SHOW_STATISTICS ('dbo.Orders', 'IX_Orders_OrderDate');

-- Only the header (most useful for freshness checks)
DBCC SHOW_STATISTICS ('dbo.Orders', 'IX_Orders_OrderDate') WITH STAT_HEADER;

-- Only histogram
DBCC SHOW_STATISTICS ('dbo.Orders', 'IX_Orders_OrderDate') WITH HISTOGRAM;

-- Only density vector
DBCC SHOW_STATISTICS ('dbo.Orders', 'IX_Orders_OrderDate') WITH DENSITY_VECTOR;

The header shows the most important freshness indicators:

Name                   Updated                   Rows    Rows Sampled  Steps  Density  ...
---------------------  ------------------------  ------- ------------  -----  -------  ---
IX_Orders_OrderDate    Jun 10 2026  3:15PM        9824033   984403       200   1.0E-7   ...

• Rows — row count when statistics were last built
• Rows Sampled — rows actually read (sample vs full scan)
• Updated — timestamp of last statistics update

Auto-Create Statistics

With AUTO_CREATE_STATISTICS ON (the default), the optimizer silently creates single-column statistics on any column referenced in a WHERE or JOIN predicate when it has no existing statistics for that column. This happens during query compilation — the first execution of the query is delayed while statistics are built.

-- Check current setting
SELECT name, is_auto_create_stats_on, is_auto_update_stats_on
FROM sys.databases
WHERE name = DB_NAME();

-- Disable (rarely advisable)
ALTER DATABASE YourDB SET AUTO_CREATE_STATISTICS OFF;

Disabling auto-create is useful only on OLAP systems where you control all statistics manually with full-scan updates. For OLTP, leave it ON.

Auto-Update Threshold: The 20% Rule and Trace Flag 2371

By default, SQL Server auto-updates statistics after approximately 20% of rows have changed (inserts, updates, deletes). For a 1-million-row table that means 200,000 modifications before statistics refresh. The exact formula (pre-SQL 2016) is:

threshold = MAX(500, 0.20 × table_row_count)

This was fine for small tables but catastrophic for large ones. A 500-million-row table requires 100 million modifications before auto-update fires — meanwhile plans degrade as data drifts from the histogram.

SQL Server 2016+ fix: A dynamic threshold was introduced (enabled by default since 2016 with compatibility level 130+):

-- Check compatibility level
SELECT compatibility_level FROM sys.databases WHERE name = DB_NAME();

-- For older compat levels, enable the dynamic threshold via trace flag
DBCC TRACEON(2371, -1);  -- server-wide
-- Or per-database:
ALTER DATABASE YourDB SET AUTO_UPDATE_STATISTICS_ASYNC ON;

The dynamic threshold formula is approximately SQRT(1000 × row_count), which scales sub-linearly. A 500-million-row table now updates after ~22,000 modifications rather than 100 million.

Asynchronous Statistics Update

By default, statistics auto-update is synchronous: the query that triggers the update is blocked until statistics are rebuilt, then recompiles and executes. On a 500M-row table with WITH FULLSCAN this could block for seconds.

Asynchronous update lets the triggering query use the existing (stale) statistics and compile immediately. The update runs in the background:

ALTER DATABASE YourDB SET AUTO_UPDATE_STATISTICS_ASYNC ON;

Trade-off: the query that triggers the async update uses a potentially stale plan. The next query compilation after the background update completes will get the fresh plan. For OLTP workloads with frequent short queries, async update is almost always better — it eliminates the latency spike at the cost of one additional stale-plan query execution.

Diagnosing Stale Statistics

Several DMVs help identify statistics that need updating:

-- Tables with high modification counters relative to row count
SELECT
    OBJECT_NAME(s.object_id)    AS table_name,
    s.name                       AS stats_name,
    sp.last_updated,
    sp.rows,
    sp.modification_counter,
    CAST(100.0 * sp.modification_counter / NULLIF(sp.rows,0) AS DECIMAL(10,2)) AS pct_modified
FROM sys.stats s
CROSS APPLY sys.dm_db_stats_properties(s.object_id, s.stats_id) sp
WHERE OBJECTPROPERTY(s.object_id,'IsUserTable') = 1
  AND sp.modification_counter > 0
ORDER BY pct_modified DESC;

-- Queries with large estimated vs actual row count differences (plan cache)
SELECT TOP 20
    qs.total_elapsed_time / qs.execution_count       AS avg_elapsed_us,
    qs.execution_count,
    SUBSTRING(qt.text, qs.statement_start_offset/2+1,
        (CASE WHEN qs.statement_end_offset = -1 THEN LEN(qt.text)*2
              ELSE qs.statement_end_offset END - qs.statement_start_offset)/2+1) AS query_text
FROM sys.dm_exec_query_stats qs
CROSS APPLY sys.dm_exec_sql_text(qs.sql_handle) qt
CROSS APPLY sys.dm_exec_query_plan(qs.plan_handle) qp
WHERE qp.query_plan LIKE '%StatisticsInfo%'
ORDER BY avg_elapsed_us DESC;

Manual UPDATE STATISTICS Options

The basic syntax updates all statistics on a table:

UPDATE STATISTICS dbo.Orders;

Key options:

-- Full scan (most accurate, most I/O)
UPDATE STATISTICS dbo.Orders WITH FULLSCAN;

-- Specific statistics object only
UPDATE STATISTICS dbo.Orders IX_Orders_OrderDate WITH FULLSCAN;

-- Sample percentage (trades accuracy for speed)
UPDATE STATISTICS dbo.Orders WITH SAMPLE 30 PERCENT;

-- Sample row count
UPDATE STATISTICS dbo.Orders WITH SAMPLE 500000 ROWS;

-- Resample — reuse the same sample rate as the previous update
UPDATE STATISTICS dbo.Orders WITH RESAMPLE;

-- No recompute — update but suppress auto-update flag (prevents future auto-updates)
UPDATE STATISTICS dbo.Orders WITH NORECOMPUTE;  -- use with caution

Filtered Statistics for Skewed Data

When a column has highly skewed distribution — for example, 95% of orders have Status = 'Completed' and 5% have Status = 'Pending' — a single histogram averages across the entire distribution. Queries filtering on Status = 'Pending' get poor estimates.

A filtered statistics object focuses the histogram on a specific subset:

-- Create filtered statistics on the sparse value
CREATE STATISTICS stat_Orders_Pending
ON dbo.Orders (OrderDate, CustomerID)
WHERE Status = 'Pending'
WITH FULLSCAN;

-- Filtered index (automatically creates filtered statistics)
CREATE INDEX IX_Orders_Pending_Date
ON dbo.Orders (OrderDate)
INCLUDE (CustomerID, Total)
WHERE Status = 'Pending';

With filtered statistics, a query WHERE Status = 'Pending' AND OrderDate > '2026-01-01' can use the filtered histogram and get an accurate estimate of the small result set, leading to a seek + lookup instead of a full table scan.

Multi-Column Statistics

SQL Server auto-creates only single-column statistics. If your queries filter on multiple columns with correlated values, the optimizer multiplies individual selectivities and underestimates the result set.

-- Example: Country + City are correlated — most Cities belong to one Country
-- Single-column stats will underestimate: P(Country='US') × P(City='New York')
-- Multi-column stats capture the correlation

CREATE STATISTICS stat_Customer_Country_City
ON dbo.Customers (Country, City)
WITH FULLSCAN;

SQL Server 2014+ introduced incremental cardinality estimation improvements, but multi-column stats on correlated columns remain valuable especially when the new cardinality estimator (CE 120+) is in use.

Incremental Statistics on Partitioned Tables

On large partitioned tables, updating statistics requires reading the entire table unless you enable incremental statistics (SQL Server 2014+). With incremental statistics, each partition maintains its own statistics fragment, and you can update just the modified partition:

-- Enable incremental statistics at table level
CREATE STATISTICS stat_Sales_Date
ON dbo.Sales (SaleDate)
WITH FULLSCAN, INCREMENTAL = ON;

-- Update only partition 12 (the current month)
UPDATE STATISTICS dbo.Sales stat_Sales_Date
WITH RESAMPLE ON PARTITIONS(12);

-- Check which partitions have stale stats
SELECT
    object_name(s.object_id)   AS table_name,
    s.name                      AS stats_name,
    ddsp.partition_number,
    ddsp.last_updated,
    ddsp.rows,
    ddsp.modification_counter
FROM sys.stats s
CROSS APPLY sys.dm_db_incremental_stats_properties(s.object_id, s.stats_id) ddsp
WHERE s.object_id = OBJECT_ID('dbo.Sales')
ORDER BY ddsp.partition_number;

Statistics Maintenance Script

A practical maintenance routine updates statistics with FULLSCAN for objects with high modification ratios, and uses sampling for the rest:

-- Update all statistics where > 10% of rows modified (FULLSCAN)
-- and > 1% but <= 10% with 30% sample
DECLARE @sql NVARCHAR(MAX) = N'';

SELECT @sql += N'UPDATE STATISTICS ' +
    QUOTENAME(OBJECT_SCHEMA_NAME(s.object_id)) + '.' +
    QUOTENAME(OBJECT_NAME(s.object_id)) + ' ' +
    QUOTENAME(s.name) +
    CASE
        WHEN CAST(100.0 * sp.modification_counter / NULLIF(sp.rows,0) AS DECIMAL(10,2)) > 10
        THEN ' WITH FULLSCAN;' + CHAR(10)
        ELSE ' WITH SAMPLE 30 PERCENT;' + CHAR(10)
    END
FROM sys.stats s
CROSS APPLY sys.dm_db_stats_properties(s.object_id, s.stats_id) sp
WHERE OBJECTPROPERTY(s.object_id,'IsUserTable') = 1
  AND sp.modification_counter > 0
  AND CAST(100.0 * sp.modification_counter / NULLIF(sp.rows,0) AS DECIMAL(10,2)) > 1
ORDER BY CAST(100.0 * sp.modification_counter / NULLIF(sp.rows,0) AS DECIMAL(10,2)) DESC;

PRINT @sql;
-- EXEC sp_executesql @sql;  -- Uncomment to execute
