SQL Server Columnstore Indexes: Delta Stores, Row Groups and Batch Mode (2026)

Row-Store vs Column-Store: The Core Difference

A traditional B-tree index stores rows: all columns of a row are physically adjacent on the same 8 KB page. To read 3 columns from 1 million rows, SQL Server must read every page containing those rows — including all the other columns you didn't ask for.

A columnstore index stores columns: all values of a single column are stored together, compressed, in a column segment. To read 3 columns from 1 million rows, SQL Server reads only the 3 column segments for those columns — skipping the other 47 columns entirely.

-- Row store layout (simplified)
Page 1: [Row1: Col1,Col2,...,Col50] [Row2: Col1,Col2,...,Col50] ...
Page 2: [Row101: ...]

-- Columnstore layout
Col1_Segment: [Row1.Col1, Row2.Col1, ..., Row1048576.Col1]  ← compressed
Col2_Segment: [Row1.Col2, Row2.Col2, ..., Row1048576.Col2]  ← compressed
...
Col50_Segment: [Row1.Col50, ..., Row1048576.Col50]           ← compressed

Row Groups: 1,048,576 Rows per Segment

Data in a columnstore index is organised into row groups — each holding up to 1,048,576 rows (2²⁰). For each row group, there is one column segment per column.

Row group states:

• COMPRESSED — fully loaded, VertiPaq-compressed, immutable. The normal state for bulk-loaded data.
• OPEN — a delta store row group accepting new inserts, stored as a B-tree. Up to 1,048,576 rows, then closed.
• CLOSED — delta store row group full, waiting for the tuple mover to compress it.
• TOMBSTONE — a compressed row group that has been deleted and is awaiting cleanup.

Row groups with fewer than ~102,400 rows (10% of max) are called trimmed row groups — they compress poorly and slow scans. Many small row groups are a sign of row-by-row inserts rather than bulk loads.

VertiPaq Compression: Encoding Schemes

SQL Server applies one of several encoding schemes per column segment, choosing the one that produces the best compression for that column's data:

These encodings are applied before the segment is also compressed with LZ4 (COLUMNSTORE_ARCHIVE compression) or left with just the encoding (COLUMNSTORE). You can choose:

-- Standard columnstore compression (default)
CREATE CLUSTERED COLUMNSTORE INDEX CCI_Sales ON dbo.Sales;

-- Archive compression (higher ratio, slower access — for cold partitions)
CREATE CLUSTERED COLUMNSTORE INDEX CCI_Sales ON dbo.Sales
WITH (DATA_COMPRESSION = COLUMNSTORE_ARCHIVE);

The Delta Store: Handling DML on Columnstore

Columnstore segments are immutable — you cannot insert a row into a compressed segment. Instead, inserts go to the delta store, which is a traditional B-tree rowstore structure. The delta store accumulates rows until it is full (1,048,576 rows), then the tuple mover compresses it into a new columnstore segment.

DELETE from a columnstore: the row is not physically removed from the compressed segment. Instead, a delete bitmap records the deleted rows. Queries skip rows flagged in the delete bitmap. Physical removal happens during an index rebuild.

UPDATE = DELETE (marks old row in delete bitmap) + INSERT (adds new row to delta store).

-- Check delta store and delete bitmap state
SELECT
    rg.object_id,
    OBJECT_NAME(rg.object_id)   AS table_name,
    rg.row_group_id,
    rg.state_description,
    rg.total_rows,
    rg.deleted_rows,
    rg.size_in_bytes / 1024     AS size_kb,
    rg.trim_reason_desc
FROM sys.dm_db_column_store_row_group_physical_stats rg
WHERE rg.object_id = OBJECT_ID('dbo.Sales')
ORDER BY rg.row_group_id;

The Tuple Mover: Delta to Compressed

A background thread called the tuple mover monitors CLOSED delta store row groups and compresses them into columnstore segments. It runs automatically and requires no configuration.

Triggering conditions:

• A delta store row group reaches 1,048,576 rows (CLOSED state)
• The tuple mover background thread wakes up (runs approximately every 5 minutes)

You can force immediate compression of closed row groups with an index reorganize:

-- Force tuple mover to compress all CLOSED delta stores
ALTER INDEX CCI_Sales ON dbo.Sales REORGANIZE
WITH (COMPRESS_ALL_ROW_GROUPS = ON);

Batch Mode Execution

Batch mode is a query execution model where operators process batches of ~900 rows at a time rather than one row at a time. This dramatically reduces per-row overhead (function call, null check, type conversion) and enables SIMD CPU vectorization.

Batch mode is automatically used when:

• A query accesses a columnstore index (SQL 2012+)
• A query is eligible for batch mode on rowstore — SQL Server 2019+ with compatibility level 150 can use batch mode for hash joins and aggregates even without a columnstore index, when batch mode is beneficial

You can see batch mode in an execution plan: operators show Estimated Execution Mode: Batch in their properties. The "Columnstore Index Scan" and "Hash Match" are the most common batch-mode operators.

-- Force batch mode on a query (useful for testing)
SELECT SUM(Amount), COUNT(*), ProductID
FROM dbo.Sales
GROUP BY ProductID
OPTION (USE HINT('ENABLE_PARALLEL_PLAN_PREFERENCE'));

-- Check if batch mode is being used
-- Look for "Actual Execution Mode = Batch" in the actual execution plan

Segment Elimination: Skipping Row Groups

Each column segment stores min/max statistics (minimum and maximum value in the segment). When a query has a predicate like WHERE SaleDate = '2026-06-11', SQL Server compares the predicate value against each row group's min/max for the SaleDate column. Row groups where the predicate value falls outside the min/max range are skipped entirely — no I/O, no decompression.

This is called segment elimination and is the second major performance advantage of columnstore (after column projection). On a 5-year fact table partitioned by month, a query for one month skips 98% of row groups.

-- Check segment elimination effectiveness (after running a query)
-- Look for "Segment Reads" vs "Segment Skips" in the execution plan XML
-- Or use Extended Events:
SELECT * FROM sys.dm_db_column_store_row_group_physical_stats
WHERE object_id = OBJECT_ID('dbo.Sales')
ORDER BY row_group_id;
-- High deleted_rows + many OPEN/CLOSED groups = needs REBUILD

Clustered Columnstore Index

A Clustered Columnstore Index (CCI) is the primary storage structure — it replaces the heap or clustered B-tree. All rows in the table are stored in columnstore format. There is no separate copy of the data.

-- Create a new table with CCI as primary storage
CREATE TABLE dbo.SalesFact (
    SaleID       BIGINT NOT NULL,
    ProductID    INT NOT NULL,
    CustomerID   INT NOT NULL,
    SaleDate     DATE NOT NULL,
    Amount       DECIMAL(18,2) NOT NULL,
    Quantity     INT NOT NULL,
    RegionCode   CHAR(3) NOT NULL
);
CREATE CLUSTERED COLUMNSTORE INDEX CCI_SalesFact ON dbo.SalesFact;

-- Convert existing rowstore table to CCI (drops existing clustered index)
CREATE CLUSTERED COLUMNSTORE INDEX CCI_Orders ON dbo.Orders
WITH (DROP_EXISTING = OFF, ONLINE = ON);  -- ONLINE requires Enterprise

CCI is ideal for:

• Data warehouse fact tables with 10M+ rows
• Tables accessed primarily by aggregations, not single-row lookups
• Historical/archive tables with mostly read traffic

Non-Clustered Columnstore Index (HTAP)

A Non-Clustered Columnstore Index (NCCI) adds columnstore storage alongside an existing B-tree (clustered or heap). The original row-store remains for OLTP point lookups; the NCCI accelerates analytical aggregations on the same table. This is the HTAP (Hybrid Transactional/Analytical Processing) pattern.

-- Add NCCI to an existing OLTP table
CREATE NONCLUSTERED COLUMNSTORE INDEX NCCI_Orders_Analytics
ON dbo.Orders (OrderDate, ProductID, CustomerID, Amount, Quantity)
WHERE OrderDate >= '2024-01-01';  -- filtered: only recent data for analytics

The optimizer automatically chooses between the B-tree and the NCCI based on estimated cost. OLTP queries (seek by OrderID) use the clustered B-tree. Analytics queries (SUM(Amount) GROUP BY ProductID) use the NCCI with batch mode.

Creating Columnstore Indexes

-- Clustered columnstore (replaces existing storage)
CREATE CLUSTERED COLUMNSTORE INDEX CCI_Sales ON dbo.Sales
WITH (MAXDOP = 8, ONLINE = ON);  -- ONLINE = ON requires Enterprise

-- Non-clustered columnstore (alongside B-tree)
CREATE NONCLUSTERED COLUMNSTORE INDEX NCCI_Orders
ON dbo.Orders (SaleDate, ProductID, Amount, Quantity, CustomerID);

-- With row group ordering hint (SQL 2022+)
-- Sorts data by SaleDate before building segments → better segment elimination
CREATE CLUSTERED COLUMNSTORE INDEX CCI_Sales ON dbo.Sales
ORDER (SaleDate);

-- Archive compression for cold data
CREATE CLUSTERED COLUMNSTORE INDEX CCI_SalesArchive ON dbo.SalesArchive
WITH (DATA_COMPRESSION = COLUMNSTORE_ARCHIVE);

Monitoring Columnstore Health

-- Row group health overview
SELECT
    OBJECT_NAME(object_id)      AS table_name,
    index_id,
    state_description,
    COUNT(*)                    AS row_group_count,
    SUM(total_rows)             AS total_rows,
    SUM(deleted_rows)           AS deleted_rows,
    100.0 * SUM(deleted_rows)
          / NULLIF(SUM(total_rows),0) AS deleted_pct,
    AVG(total_rows)             AS avg_rows_per_group,
    SUM(size_in_bytes)/1048576  AS total_mb
FROM sys.dm_db_column_store_row_group_physical_stats
WHERE object_id = OBJECT_ID('dbo.Sales')
GROUP BY object_id, index_id, state_description
ORDER BY state_description;

-- Identify poorly filled row groups (< 100K rows = trimmed)
SELECT
    OBJECT_NAME(object_id)  AS table_name,
    row_group_id,
    total_rows,
    trim_reason_desc,
    state_description
FROM sys.dm_db_column_store_row_group_physical_stats
WHERE total_rows < 102400
  AND state_description = 'COMPRESSED'
  AND object_id = OBJECT_ID('dbo.Sales')
ORDER BY total_rows;

Columnstore Maintenance: Rebuild vs Reorganize

REORGANIZE — online, incremental:

• Compresses all CLOSED delta stores (runs the tuple mover)
• With COMPRESS_ALL_ROW_GROUPS = ON: also compresses small OPEN delta stores
• Merges small compressed row groups together (SQL 2016+)
• Does NOT remove deleted rows from compressed segments

REBUILD — offline (or online with Enterprise):

• Removes all deleted rows from compressed segments
• Merges small row groups into full ones
• Re-applies optimal compression to all segments
• Resets statistics

-- Reorganize (online, minimal blocking)
ALTER INDEX CCI_Sales ON dbo.Sales REORGANIZE
WITH (COMPRESS_ALL_ROW_GROUPS = ON);

-- Rebuild (offline by default; ONLINE requires Enterprise edition)
ALTER INDEX CCI_Sales ON dbo.Sales REBUILD
WITH (MAXDOP = 8, ONLINE = ON);

-- Rebuild recommendation: when deleted_pct > 20% or avg_rows_per_group < 500K
